30 Degree Escalator For Shopping Mall

  • DE


Product Description


An escalator is a fixed electric drive device with circular running steps that is used to tilt up or down to transport passengers.

The escalator consists of a ladder road (modified slat conveyor) and handrails (deformed belt conveyor) on both sides. Its main components include steps, traction chains and sprockets, guide rail systems, main transmission systems (including motors, deceleration devices, brakes and intermediate transmission links, etc.), drive spindles, ladder road tensioning devices, handrail systems, comb boards, and escalator frames And electrical systems. The steps move horizontally at the passenger entrance (for passengers to board the stairs), and then gradually form steps; near the exit, the steps gradually disappear, and the steps move horizontally again. These movements are realized by the main and auxiliary wheels walking along different step guide rails respectively.


Product description:

Handrail: Black rubber

Balustrade: Tempered glass, height 900mm

Skirt panel: Hairline

Floor plate: Hairline

Truss: Welded mild steel(Angle bar)


Quick details:

Place of Origin: Zhejiang, China

Brand Name: DELFAR

Step width: 600~1200mm

Angle: 30 degree, 35 degree

Speed: 0.5mps.

Delivery time: 30 days.

Warranty: 12 months since the date of delivery.

Payment terms: T/T


Standard features:

Emergency stop button

Step chain protection

Skirting brush

Drive chain broken protection device

Inspection operation

Unintentional reversal protection device

Step lost protection


Optional features:

VVVF function

Skirt illumination

Automatic start/stop with running direction indicator

Handrail illumination

Comb illumination

Skirting panel with anti-friction coating


Application place:



Shopping Mall



Use strong exporting plywood cases, suitable for long distance transportation and well protected against dampness, moisture, shock and rust.


Company Introduction

Company Introduction:

DELFAR Elevator Co., Ltd. is a specialized elevator enterprise that designs, manufactures and processes the elevators and parts. The company is established in 2011, with excellent technology advantage and incorporating the elevator manufacturing techniques, we can design and produce various types of elevator product which can satisfy customer’s diversified requirements, our product includes 9 series which are Passenger elevator, Observation elevator, Bed elevator, Freight elevator, Car elevator, Dumbwaiter, Home elevator, Escalator, Moving walk. In order to satisfy the requirements from different areas, users and levels, the company has established one-continuous-line of effective work system such as the elevator design, manufacture, installation, transformation, repair and maintenance etc. From design to manufacture, from installation to maintenance, we endeavor to satisfy the clients’ individual requirements.

Factory Introduction:

Company Certificate:

Packaging and transportation

Packaging and transportation:

Special packaging material for escalators0 (3)

0 (2)





Truss adopts superior unique structure, high intensity, thorough anti- rusting treatment, fine effect, long life. Advanced international manufacture craft, final assembly tooling ensure accurate stairway.

home elevator advantage


Service :

Professional team to conduct timely and efficient communication.

Experienced installation team for guidance.

24-hour online after-sales service.

home elevator Service
